Built on a tight site in east London, these four low-cost apartments for the Peabody Trust comprise four pod-like flats that occupy a triangular site at the end of a terrace of Victorian houses.

The ground-floor flats open onto their own gardens and patio decks, while the first-floor flats are connected by a prefabricated steel and timber structure which incorporates stair access and private outdoor deck-space for the upper flats, where occupants can encounter each other in space that is simultaneously private and shared.

Ash Sakula were commissioned following a competition held by Peabody called 'Fresh Ideas for Low Cost Home Ownership' which was open to small practices with less than seven staff. The project is an early example of shared ownership affordable housing.

A close-up detail of the facade at the entrance to one of the upper apartments. Profiled translucent fibreglass back by silver foil, with strands of electrical cable in the interstices. Chain link fencing surrounds each upper flat's terrace.

Being briefed to produce two-bedroom apartments, each measuring just 67m², precipitated a re-appraisal of the spatial priorities of the traditional small flat, which resulted in an unconventional but extremely workable configuration.

The dwellings are identically arranged around an enlarged hallway where the space is both light and complex - anything but a corridor. It is large enough to hold a desk or daybed, a place to sort laundry or an area for children to play.

Bedrooms are kept as small as possible. Clothes, for example, are stored elsewhere. While the kitchen is the main social space of the flat, the living room is a cosy (with)-drawing room that can also be a home office or guest room.

Bathrooms and WCs are separate. Each is spacious, has a large basin and an opening window.

The plan above was made at competition stage.

Ash Sakula drawings photos
Ash Sakula drawings photos
Ash Sakula drawings photos
Ash Sakula drawings photos
Read more about the thinking behind this project:

The corrugated cladding set against silver foil creates lavender and turquoise reflections. In the corrugation's interstices are suspended twisted strands of black and white electrical cabling, adding to the kinetic parallax illusion created as one passes the buildings - an effect developed by Ash Sakula in collaboration with the artist Vinita Khanna.

A few weeks after the residents moved in we received this painting from the Brewer family. It said, "Thank you for our incredible home." In an accompanying letter the Brewers wrote, "... we have never seen anything better designed for us as a family. Thank you for all your thoughtful hard work."

Animators Wrench & Franks made a short video of the project. Here is a still from the closing sequence.

Client: Peabody Trust

Artist collaborator: Vinita Khanna

Structural Engineer: Whitby Bird

MEP: Atelier 10

PM and QS: Walker Management

Area: 4 x 67m²

Site area: 472m²

Value: £618,000

Completed: 2004
